STARTING SYSTEM
Manual S /Electric S and L
WEIGHT LBS
Manual S: 136.6 / Electric S: 143 - Electric, Tiller, Power Trim and Tilt L: 163
ENGINE TYPE
SOHC 4-Valve
FUEL DELIVERY SYSTEM
Suzuki Battery-less Electronic Fuel Injection with Lean Burn Control
NO. OF CYLINDERS
3
PISTON DISPLACEMENT INCHES (CC)
29.8 (489)
BORE X STROKE INCHES (MM)
2.80 x 2.68
MAXIMUM OUTPUT HP
25
OPERATING RANGE (RPM)
5000 - 6000
STEERING
Tiller/Remote
CHOKE
N/A - Suzuki Electronic Fuel Injection
OIL PAN CAPACITY QUARTS (LITER)
1.6 (1.5)
IGNITION SYSTEM
Digital CDI
ALTERNATOR
Manual 12V 14A / Electric 12V 14A
TRIM POSITION
5 Tilt Pin Positions - Manual / Power Tilt and Trim
GEAR RATIO
2.09:1
STANDARD PROPELLER
3 x 9.25 x 10
PROPELLER SELECTION
7 - 11
